8T Wheeled Excavator with Maximized Capabilities
YUFAN is a leading 8t wheeled excavator factory in China. We prioritize productivity and safety in our wheeled mini excavators.
Our 8 ton wheel excavators are friendly to road surface, and can move on the road directly without a trailer. A 8 ton wheel excavator can perform flexible operation in narrow spaces!
> Fast Transfer: 28km/h for quick site moves.
> Powerful Yuchai Engine: Strong, durable, emission-comppliant.
> Agile Operation:Small swing radius for tight spaces.
> OEM/ODM is available.
> Supported by SOEs group for R&D and production.
> Certified with ISO 9001, SGS, and CE.
> Ideal for digging, trenching, construction, and demolition.
8T Crawler Excavator vs 8T Wheeled Excavator
Choose 8 ton crawler excavator or 8 ton wheeled excavator? It depends on your usage scenarios, efficiency requirements, and cost budget. A table helps you make a wise choice.
| Aspects | 8T Wheeled Excavator | 8T Crawler Excavator |
| Move Mode | Tire walking, can hit the road directly. | Crawler travel, needs transport tailer |
| Transition Efficiency | Very high, no trailer required | Lower, relying on trailer |
| Impact on the Ground | No damage | Easily damaging |
| Suitable for | Urban roads, hard ground | Muddy ground, mountainous areas, and complex working conditions |
| Budget | Lower | Higher |
YFT80W - YUFAN 8 Ton Wheel Excavator Specifications
- Specification
- Working range
- Machine size
| Specification | |
|---|---|
| Bucket Capacity (m³) | 0.3 |
| Swing Speed (rpm) | 0–12 |
| Gradeability (°) | 25 |
| Max. Bucket Digging Force (kN) | 45 |
| Max. Arm Digging Force (kN) | 36 |
| Engine Model | YCF3065–T480 |
| Power/revolution speed (kW/rpm) | 48/2200 |
| Tire Model | 8.25–16 |
| System Pressure (MPa) | 24 |
| Working range | |
|---|---|
| Max. Digging Height (mm) | 7154 |
| Max. Dumping Height (mm) | 5330 |
| Max. Digging Depth (mm) | 3765 |
| Max. Vertical Digging Depth (mm) | 2726 |
| Max. Digging Radius (mm) | 6178 |
| Min. Swing Radius (mm) | 1737 |
| Max. Dozer Blade Lifting Distance (mm) | 370 |
| Max. Dozer Blade Cutting Distance (mm) | 131 |
| Machine size | |
|---|---|
| Dimension (Length×Width×Height) (mm) | 6308×2238×2718 |
| Cabin Height (mm) | 2718 |
| Axle Base (mm) | 2399 |
| Wheel(track) Distance (mm) | 1694 |
| Minimum ground clearance (mm) | 260 |
| Tail Swing Radius (mm) | 1797 |
8 Ton Wheeled Excavator Parts and Functions
Engine– YUFAN 5 ton excavator for sale is equipped with a 4-cylinder engine.
– High-performance with efficient fuel consumption.
Water Cooling– Vacuum brazing technology for heat transfer efficiency.
– Allows the excavator to operate effectively in hot weather.
Main Control– Features a high-tech main control valve.
– Integrates boom, joystick, and bucket controls for operation.
Welding Tech– Entirely welded by automatic equipment.
– High-strength steel derrick and bucket with internal baffles.
Boom Cylinder– Boasts an integrated casting boom cylinder.
– Includes a protective cover for maximum protection.
Structural Parts– Constructed from high-quality 16mm steel.
– Enhanced strength with shot blasting polishing for extended life.
Things You Should Know Before Buying a YUFAN Excavator
Consider what tasks you need the machine to perform and what terrain it will operate on. Different applications will lead to different types of excavators.
Look for appropriately sized equipment that can handle the tasks you have in mind. Make sure to check the weight and dimensions of the machine with YUFAN online specialist.
Consider the operating costs of the machine, including fuel consumption, maintenance, and repair costs for your projects.
YUFAN compact equipment has appropriate safety features such as roll-over protection, seat belts, and backup alarms.
Look for financing options that suit your budget. YUFAN machinery always comes with a one-year warranty covering any defects.
YUFAN team offers good customer support, including parts availability, service and repair, and operation guidance.
Partner with YUFAN for Excellent Performance
Discover More Mini Excavator Models
FAQs
YUFAN 8t wheeled excavators are typically used for various tasks, such as digging, trenching, and tree installation/removal.
Our 8 ton wheeled excavator is equipped with a quick coupler and auxiliary hydraulics, allowing it to pair with mini excavator attachments for increased versatility and productivity.
