YUFAN Machinery Tracked Skid Steer
YUFAN — a professional track skid steer manufacturer in China. We are always dedicating to manufacturing the best tracked skid steer.
YUFAN skid steer with tracks – the representative of Chinese tracked skid steer. Especially in muddy conditions, it possesses performance that wheeled skid steer loaders cannot achieve. It is more stable, durable and efficient!
No matter if you are for residential use, take on some projects on weekends, or rent out. YUFAN tracked skid steer can fulfill 80% of your work requirements!
Why Choose Tracked Skid Steer
YUFAN Track Skid Steer - Find the Right Size for Your Job
Small/Mini Track Skid Steer
This track skid steer weighs 941kg, with a body width of 910mm. It is equipped with:
✅ High-stability triangular rubber tracks
✅ High efficiency hydraulic oil cooler
✅ High quality travel motor- Engine Brand
- Lithium electricity/KOOP/Rato/B&S
- Engine Power
- 6kw,72V,125ah/7.6(7)/7.9/9.92kw
- Cylinder
- 1
- Emission standard
- EPA/ERUO5
- Fuel tank capacity
- 5L
- Overall dimensions
- 2092*1050*1300mm
- Track contact length
- 900mm
- Track model
- 180*72*35
Compact Track Skid Steer
This track skid steer weighs 1892kg, with a body width of 960mm. Its outstanding features:
✅A filter element on the side – It’s convenient for you to perform maintenance at any time.
✅Imported motor – A higher flow rate and stability.
✅Kubota engine – Key to durability
✅Imported branded pump body
✅55 attachments – Suitable for various uses, whether for agricultural, forestry, utility work or household purposes, and can basically meet its requirements.- Engine Brand
- Yanmar/Kubota
- Engine Power
- 15.2(17.8)/17.1kw
- Cylinder
- 3
- Emission standard
- EPA4/ERUO5
- Fuel tank capacity
- 40L
- Overall dimensions
- 2691*1240*1548mm
- Track contact length
- 1080mm
- Track model
- 230*72*45
Large Track Skid Steer
This track skid steer weighs 5100kg, with a body width of 2124mm.
✅ YUFAN’s largest crawler skid steer loader.
✅ Higher hydraulic flow rate.
✅ Quite a high safety factor.
✅ Pilot control, easier to operate- Engine Brand
- Weichai
- Engine Power
- 103/2300 kW/rpm
- Engine displacement
- 4.088 L
- Emission standard
- EPA4/ERUO5
- Rated load (kg)
- 1500
- Bucket capacity (m³)
- 0.6
- Max Speed (km/h)
- 12/18
- Max traction (kN)
- >32
Beyond Product, Our Solution
1. Customer background: a palm oil production company in Ghana.
2. Customer working environment: forestry operations
3. Track skid steer that the client bought: YUFAN TS125
4. The client’s 5 challenges and YUFAN’s solution provided to the client for forestry operations:
Challenge 1: Muddy ground, loose soil and steep slopes
YUFAN TS125 tracked skid steer: Larger contact area with the ground, more stable and safer
Challenge 2: Luxuriant trees and branches, more risks to get stuck
YUFAN TS125 tracked skid steer: Smoother movement. Less risk for tracks to get damaged and punctured. It is durable and has a long lifespan.
Challenge 3: Complex work in forest. Requires high hydraulic flow
YUFAN TS125 tracked skid steer: Various auxiliary tools to be selected to complete different kinds of jobs. High hydraulic flow. Controlled by a pilot system, making it easier to operate.
Challenge 4: Ordinary door glass is easily broken by the abundant branches.
YUFAN TS125 tracked skid steer: replaced it with acrylic glass and installed a protective cover on the outside, providing double insurance for the client.
Challenge 5: Tropics temperature is hot and humid. Poor comfort during operation.
YUFAN TS125 tracked skid steer: Equip with an air conditioner to provide a comfortable working environment for the driver.
Skid Steer on Tracks
Skid Steer Tracks
YUFAN best rubber track skid steer:
🔹Standard configuration: high-performance steel-embedded triangular rubber tracks
🔹Thickened and steel-lined, special tracks for construction machinery, wear-resistant and crack-resistant, with irreplaceable passability in muddy, soft and slippery terrains
🔹The tracks are installed in one direction
🔹Up to 3,000 hours lifespan
🔹Easy to replace and reset
For any questions, feel free to contact our service team, and we will provide detailed video guidance within 24 hours.
Application
Explore Our Big Wheel Excavator Attachments
If you are having trouble deciding between a track and a wheel skid steer, the following table can help you make your choice:
| Muddy land, rotten land, sloping land, paddy fields, sandy land, grassland | → Choose a track skid steer |
| Cement roads, gravel, hard ground in courtyards, highways, and more transitions requirement | → Choose a wheel skid steer |
Some customers put tracks over tires, but this also comes with risks. If a tire bursts, you have to remove the tracks first before making any repairs, which is very troublesome.
When purchasing a skid steer loader, you should choose based on your usage scenario.
Still have any questions? Feel free to contact the YUFAN service team! Or check out this article: Track vs Wheel Skid Steer for answers.
It is possible. But YUFAN does not recommend to do so. If you really want, there are two ways to convert: one does not require removing the tires, and the other requires removing the wheels.
METHOD 1. Leave the wheels as they are, but put tracks on a wheeled skid steer
1) No need to remove the wheels.
2) Put this track wrapping device over the tire
3) Use clips or bolts to fix it to the hub or rim.
4) Adjust the tension slightly and you can start working directly.
METHOD 2. Remove the wheels and replace them with a track walking assembly. Then adjust the center of gravity and the hydraulic system. It will be usable.
YUFAN does not recommend unauthorized conversion. One reason is that the modified vehicle may not meet safety standards. The other is that the overall warranty and after-sales service for the modified vehicle will no longer be covered.
Track loader is not skid steer.
▪️Track loaders: includes track skid steer loader and ordinary track loader
▪️Skid steer loaders: includes track skid steer loaders and wheeled skid steer loader
Only the track skid steer loader belongs to both track loader and skid steer. The following table shows their relationships clearly:
| – | Wheeled skid steer loader (Make a 360° in-place turn) | Skid Steer |
| Track Loader | Tracked skid steer (Make a 360° in-place turn) | |
| Ordinary track (crawler) loader, non-skid steer (cannot turn 360° on the spot) | – |
