China 4 Ton Excavator
YUFAN is a leading 4 ton excavator manufacturer in China. We work closely with every client to guarantee your requirements are fulfilled with our services. We stand behind our machines and are always available to address any inquiries or concerns you may have.
YUFAN 4-ton excavator YFT40 is equipped with a powerful engine and hydraulic system. It runs on a Kubota engine that meets the Stage V emission standard.
The hydraulic system of YFT40 is highly efficient. Ensuring smooth movements of the boom, arm, bucket, and swing motor. Making it one of the best-performing excavators in its weight class.
> Zero Tail Swing for Unrestricted Operation:Zero tail swing enables optimal flexibility in various working scenarios.
> Swift delivery within 7-14 days.
> Pro-Performance In A Compact Frame.
> Advanced Load-Sensing Hydraulics.
> Operator-Centric Premium Cabin (ROPS/FOPS Certified).
> Provides OEM solutions with a one-year warranty.
> Compatible with various attachments. Buckets, grapple, quick coupler, etc.
4 Ton Excavator For All Your Excavation Needs
Good Founctionality· Easier access to key components such as hydraulic lines and engines.
· Run a wider variety of accessories, improving cycle time and overall productivity.
Fuel Consumption· More flexibility in small spaces compared to larger excavator models.
· Lower fuel consumption rates and maintenance costs.
Types of Tracks· Steel tracks provide excellent traction and optimum resistance to demolition conditions.
· Rubber tracks are gentler and more durable on finished surfaces.
4 Ton Excavator Specifications
Engine Kubota D1703 Power 18.5/25hp@2200rpm Emission standard Euro V Cylinders 3 Bucket capacity 0.12m³ Ground clearance 295mm Max. travel speed 4.4km/h Machine weight 3810kg Dimensions 4915*1720*2525mm Axle base 1670mm Track gauge 1420mm Track width 300mm Track length 2154mm Swing radius/front 2835mm Swing radius/tail 860mm Max. gradability 30° Max. digging H 4800mm Max. dumping H 3406mm Max. digging D 3208mm Vertical digging D 2957mm Digging distance 5480mm Blade lifting H 365mm Boom swing angle 50°/60° Digging force/bucket 30.4kn
Zero Tail Swing 4 Ton Excavator
4-ton excavator has a compact framework that is specially designed for tight spaces. Even when working close to walls or other obstacles, it can carry out excavation tasks as normal. Without constantly moving around or adjusting the distance. It helps to prevent damage to nearby structures and makes construction more flexible.
Safe Operator Space: The cab sits on a strong frame with FOPS/ROPS for extra protection. We’ve also included a hidden safety belt and a safety hammer to keep the operator safe.
4 Ton Excavator Prioritizing Operator Safety
Ensuring the safety of the operator is our top priority. The operator’s cabin is securely positioned on a strong structure. Alongside FOPS/ROPS to provide an additional layer of protection. They help to keep the operator safe from falling objects and rollovers.
We also add other safety features: safety belt, emergency button, safety hammer, and rear camera. They’re all placed within reach.
With all these safety features, operators can focus on their work with confidence. Knowing that their safety is well taken care of. And in every part of the excavator’s design.
4 Ton Excavator Essential Tools for Versatile Operations
This 4 ton mini excavator is equipped with quick coupler, thumb, multi-functional bucket and breaker hammer to perform different kinds of construction tasks. Its versatile functions are ideal for digging, grabbing, breaking, and other tasks—greatly improving work efficiency.
Driving 8000 lbs Excavator Success with YUFAN
FAQs
In most projects, Mini excavator sizes range from 3 to 5 tons normally. These are the most versatile machines and the best sizes of all.
The excavators in this size segment are fully functional and suitable for everything from removing tree stumps to leveling driveways or digging hot pools.
Excavator performance fluctuates in terms of the longest cycle time, from 45 seconds to more than 450 seconds. It’s better to be aware of the wide range of data for safety purposes.
The YFT40 is classified as a compact or mini excavator. The machine has a maximum digging depth of approximately 3″and a frontal lifting capacity of 4,080 lbs at a 2-foot loading point height and an 8-foot loading radius. Machines range in weight from 9,195 lbs to 10,210 lbs, depending on the variables.
Yes, the YUFAN 4 ton excavator is approximately equivalent to an 8000 lbs excavator.
A standard excavator weighs 19-24 tonnes but can range in weight from 10 to 45 tons. Unlike smaller sizes, standard excavators are fitted with tracks instead of wheels, making them good at navigating rough terrain. Their tread is how they got the name “crawler.”
A 4-ton excavator is incredibly versatile. It is the go-to size for medium-scale landscaping, commercial trenching (for pipes and utilities), concrete pool excavation, demolition of small structures, and foundation work. It bridges the gap by offering the lifting capacity of a medium excavator while retaining the transportability of a smaller mini digger.
Yes, absolutely. We offer both options based on your working environments. Rubber tracks are ideal for urban sites, manicured lawns, and paved roads to minimize ground surface damage. Steel tracks are highly recommended for harsh, rocky terrains or demolition sites where sharp debris might damage rubber.
Yes, it features an independent Boom Swing function. This allows the operator to swing the boom left or right independently of the house rotation, making parallel ditch digging right up against walls or obstacles extremely easy and efficient.
To ensure global compliance, we offer world-class engine options, including premium brands like Kubota, Yanmar, or Perkins depending on stock and customization. These engines are certified to meet strict US EPA Tier 4 Final and EU Stage V emission regulations, allowing for legal and eco-friendly operation in North America and European markets.
Because its operating weight is around 4,000 kg, it can typically be transported using a heavy-duty utility trailer towed by a standard commercial duty pickup truck (such as a 1-ton truck like a Ford F-350 or equivalent), depending on local towing regulations. This saves substantial mobilization costs compared to large heavy excavators.
